Carton Soap Packing Machine High Speed 20-200packs/min Automatic Flow Cover Pillow Design

Large Image : Carton Soap Packing Machine High Speed 20-200packs/min Automatic Flow Cover Pillow Design

Product Details:

Place of Origin:	Gansu, China
Brand Name:	LIMAC

Payment & Shipping Terms:

Minimum Order Quantity:	1 PC
Price:	$5,800.00/sets 1-2 sets
Packaging Details:	wooden box
Supply Ability:	10 Set/Sets per Month

Contact Now

Carton Soap Packing Machine High Speed 20-200packs/min Automatic Flow Cover Pillow Design

Description

Type:	Wrapping Machine, Packing Machine	Applicable Industries:	Manufacturing Plant
After Warranty Service:	Online Support, Field Maintenance And Repair Service	Local Service Location:	Egypt, Philippines
Showroom Location:	Philippines, Malaysia	Condition:	New
Application:	Chemical, Machinery & Hardware	Packaging Type:	Cartons
Packaging Material:	Carton	Automatic Grade:	Automatic
Driven Type:	Electric	Voltage:	220V
Weight:	1500 KG	After-sales Service Provided:	Video Technical Support, Field Maintenance And Repair Service, Video Technical Support,Online Support
Warranty:	1 Year	Key Selling Points:	High Productivity
Marketing Type:	New Product 2020	Machinery Test Report:	Provided
Video Outgoing-inspection:	Provided	Warranty Of Core Components:	More Than 5 Years
Core Components:	PLC, Gear, Motor, Engine, Pump	Product Name:	Automatic Bar Soap Pillow Packing Machine
Soap Packing:	Automatic	Production Capacity:	20-200packs/min
Packing Speed:	200carton/min	Packing Material:	Carton
Soap Size Length:	50-300mm	Soap Size Width:	25-125mm
Film Thickness:	0.03-0.07mm	Port:	Qingdao

LIMAC high speed 20-200packs/min automatic flow cover pillow packing toilet soap machine

Product Description

Cartoning machine is suitable for sachet, condom, adhesive bandage, soft ALU strip, plaster, coffee bag, face mask and similar product. It consists of direction folding (1-4folds)and feeding equipment, cardboard case forming and feeding, batch number printing, sealing of case tongues at both ends etc. The whole encasing process is finished automatically. It can be added hot-glue machine.

Main performance and structure features of automatic packing machine :
1. Double motor,double Panasonic transducer and PLC controller,flexible bag length setting and cutting.saving time and film.

2. human-machine interface,convenient and quick parameter settings.

3. Self diagnosis failure function,failure displayed clearly.
4. High sensitive optical electric color mark tracking system and digital input cut position,with make the sealing and cutting more accurate.
5. Separated PID control system for temperature,suitable for various packing materials.
6. Stopping the machine in selected position,no sticking on the knife and no waste of the film.
7. Simple driving system,reliable working,convenient maintenance.
8. All controlled by program,convenient for adjusting and upgrading.

Specification

Main technical parameters			JDZ-120G
Encasing speed			30-120cartons/min
Carton	Quality requirement	250-350g/m2
Carton		*Dimension range(LWH)*	*(70-180) (35-85) (14-50)mm*
Leaflet	Quality requirement	60-70g/ m2
		Unfolded leaflet specification	*(80-250) (90-170)mm**
		Fold range	1-4 fold
Compressed air	Working pressure	≥0.6mpa
Compressed air		Air consumption	260-300L/min
Power supply			220V 50HZ
Motor power			2.2Kw
*Machine dimension(LWH)*			*420010501600mm*
Machine weight			1600kg
