Bar Soap Vacuum Extruder Plodder Machine With Upper Extruder Speed 5-18 R/Min

Certification
China Lanzhou Limac Machinery Works Co., Ltd. certification
I'm Online Chat Now

Bar Soap Vacuum Extruder Plodder Machine With Upper Extruder Speed 5-18 R/Min

Bar Soap Vacuum Extruder Plodder Machine With Upper Extruder Speed 5-18 R/Min
Bar Soap Vacuum Extruder Plodder Machine With Upper Extruder Speed 5-18 R/Min Bar Soap Vacuum Extruder Plodder Machine With Upper Extruder Speed 5-18 R/Min Bar Soap Vacuum Extruder Plodder Machine With Upper Extruder Speed 5-18 R/Min Bar Soap Vacuum Extruder Plodder Machine With Upper Extruder Speed 5-18 R/Min Bar Soap Vacuum Extruder Plodder Machine With Upper Extruder Speed 5-18 R/Min Bar Soap Vacuum Extruder Plodder Machine With Upper Extruder Speed 5-18 R/Min

Large Image :  Bar Soap Vacuum Extruder Plodder Machine With Upper Extruder Speed 5-18 R/Min

Product Details:
Place of Origin: Gansu, China
Brand Name: LIMAC
Payment & Shipping Terms:
Minimum Order Quantity: 1 PC
Price: $5,500.00 - $19,000.00/sets
Packaging Details: Wooden Box
Supply Ability: 1 Set/Sets per Month

Bar Soap Vacuum Extruder Plodder Machine With Upper Extruder Speed 5-18 R/Min

Description
Condition: New Product Type: Soap, Soap Bar
Weight (KG): 5000 Machine Type: Soap Making Machine
Showroom Location: Philippines, Indonesia Video Outgoing-inspection: Provided
Machinery Test Report: Provided Marketing Type: New Product 2020
Warranty Of Core Components: More Than 5 Years Core Components: Gearbox, Motor
Warranty: 1 Year Key Selling Points: Easy To Operate
Applicable Industries: Manufacturing Plant Name: Extruder Plodder Making Machine
Capacity: 3000-4000kg/h Advantage: High Quality
Screw Diameter (mm): 350 Motor(kW): 37+37
Soap Size: Customized Speed: Upper Extruder 5 To 18 R/min
After-sales Service Provided: Video Technical Support, Online Support PACKING: Wooden Case
Port: Shanghai

Bar soap single screw vacuum extruder plodder making machine in kenya
Product Description
Bar Soap Vacuum Extruder Plodder Machine With Upper Extruder Speed 5-18 R/Min 0



Duplex single worm vacuum plodder Type 3000ES- DRVP
Super-charge Duplex single-worm vacuum plodder Type 3000ES-DRVPT
3000ES-DRVPT-300 Super-charge Duplex single-worm plodder

Totally new super-charge plodders Series ES can be used both for production low and high TFM soaps. The new plodders have innovated speed reducer design, cooling-water system/jacket design and worm design,so that the machine has reduced driving torque, uniform pressure and no backflow of soap inside the worm barrel, resulting in high productivity, easy to operate, and lower labor-intensity. The plodder is auto-protected by ielligent-control, so it has much long service life.

Technical Specification for Duplex Plodder Type 2000ES-DRDPT-A for Two-Colored Sandwich Soap
●Capacity :2000kg/h-3000kg/h finished two color sandwich soap cake. ●Worm:250mm in diameter,made from welded stainless steel 304 or Al-Mgalloy casting. Motors: 18.5KWX2 22KWX2 ●Electric heaters at the conical outlet head:2KW+1KW ●There are 8 speed reducers in the plodder. The gears of the reducer are with high precision Class 6 and the teeth are case-hardened and ground.

Lower extruder 5 to 18 r/min adjustable; The worm is with changing-pitch and changing depth, made from stainless steel 304 Warm barrel from one piece of seamless stainless steel 304 tube. Frequency adjustable A.C. drive by Mitsubishi, Japan. Electric components by Schneider, France. Duplex single-worm vacuum refiner -plodder
Specification
Item
1000-DRVP-200
1000-DRVP-250
2000G/S-DRVP-300
2000G/S-DRVP-350
2000 G/S
DRVP -400
Capacity
500kg/h
1000kg/h
2000kg/h
3000kg/h
5000kg/h
Motor Power
2*11kw
2*18.5kw
2*37kw
2*45kw
2*75kw
Weight
4000kg
5000kg
6500kg
7600kg
8800kg
Dimension
3800*1300
*2000mm
3200*1600
*2100mm
4805*1500
*2450mm
5720*1540
*2450mm
5740*2300*2800mm
Type
Capacity (kg/h)
screw diameter (mm)
Motor(kW)
4000ES-DRVPT
3000-4000
350
37+37
3000ES-DRVPT
2000-3000
300
30+30
1500ES-DRVPT
1000-1500
250
22+22
5OOES-DRVPT
500
200
11+11
1000ES-DRVPT-A
1000
200
22+22+1+0.5
2000ES-DRVPT-A
2000-3000
250
37+44+2+1
Details Images
Bar Soap Vacuum Extruder Plodder Machine With Upper Extruder Speed 5-18 R/Min 1
Bar Soap Vacuum Extruder Plodder Machine With Upper Extruder Speed 5-18 R/Min 2
Bar Soap Vacuum Extruder Plodder Machine With Upper Extruder Speed 5-18 R/Min 3
Recommend Products

Company Profile
Bar Soap Vacuum Extruder Plodder Machine With Upper Extruder Speed 5-18 R/Min 4

Limac Machinery Works Corporation, Lanzhou (LIMAC) is a professional corporation devoted herself to research, development, and manufacturing of all kind of soap machinery and equipment. The corporation owned a creative design and manufacturing team, most of them have thirty years of soap-making machinery design/ manufacturing experience. For years the corporation has produced a number of up-to-date soap-making machinery and equipment. The corporation adopts internationally new mode of cooperation, integrating domestic and foreign advanced technical and production resources, so the machinery and equipment supplied by LIMAC has been highly praised by the soap producers all over the world.
Bar Soap Vacuum Extruder Plodder Machine With Upper Extruder Speed 5-18 R/Min 5
Bar Soap Vacuum Extruder Plodder Machine With Upper Extruder Speed 5-18 R/Min 6
Exhibition
Bar Soap Vacuum Extruder Plodder Machine With Upper Extruder Speed 5-18 R/Min 7
Shipping and Payment
Bar Soap Vacuum Extruder Plodder Machine With Upper Extruder Speed 5-18 R/Min 8
FAQ
1. who are we?
We are based in Gansu, China, start from 2006,sell to Eastern Asia(30.00%),Africa(30.00%),Mid East(20.00%),Northern Europe(10.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
soap making machine,toilet soap production line,laundry soap making machine,packing machine,two colour-sandwich soap production line

4. why should you buy from us not from other suppliers?
Limac Machinery Works Corporation, Lanzhou (LIMAC) is a professional corporation devoted herself to research, development, and manufacturing of all kind of soap machinery and equipment. The corporation owned a creative design and manufacturing team.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF;
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,Western Union;
Language Spoken:English,Chinese,Spanish,Portuguese,French,Russian
