Accuracy Soap Cutting Machine Enhancing Soap Production With 2.9kw Power

Large Image : Accuracy Soap Cutting Machine Enhancing Soap Production With 2.9kw Power

Product Details:

Place of Origin:	Gansu, China
Brand Name:	limac

Payment & Shipping Terms:

Minimum Order Quantity:	1 PC
Price:	$16,500.00/sets >=1 sets
Packaging Details:	wooden box
Supply Ability:	10 Set/Sets per Month

Contact Now

Accuracy Soap Cutting Machine Enhancing Soap Production With 2.9kw Power

Description

Condition:	New	Product Type:	Soap
Weight (KG):	1000	Machine Type:	Soap Cutting Machine
Showroom Location:	Indonesia, Argentina, None	Video Outgoing-inspection:	Provided
Machinery Test Report:	Provided	Marketing Type:	New Product 2020
Warranty Of Core Components:	5 Years	Core Components:	PLC, Gearbox
Warranty:	1 Year	Key Selling Points:	High-accuracy
Applicable Industries:	Manufacturing Plant	Product Name:	Soap Cutting Machine
After-sales Service Provided:	Provide	Cutting Speed:	20 To 220 Pcs/min
Power:	2.9kw	Fuction:	Print And Cut Soap
Soap Cutting Width:	120 Mm Max	Soap Cutting Length:	60 To 999 Mm
Material:	Stainless Steel	Advantage:	High Effiency
Port:	Shanghai

High-accuracy soap bar cutter soap cutting machine soap production line

Product Description

2000ES-MFS- 6:Vertical soap stamper with freezing dies of 6 cavities

2000ES-QKI Electronic single-blade cutter is with vertical engraving rolls, used in toilet or translucent soap finishing line for preparing soap billets for soap stamping machine. All electric components are supplied by Siemens. Split boxes supplied by professional company are used for whole servo and PLC control system. The machine is noise free.
Cutting accuracy ± 1 gram in weight and 0.3 mm in length.

Capacity:
Soap cutting width: 120 mm max.
Soap cutting length: 60 to 999 mm
Cutting speed: 20 to 220 pcs/min
Configurations:
This is a mechatronic product including professional split boxes, PLC, servo control and servo motor.All parts in contact with soap are made from stainless steel or aviation hard aluminum alloy.Frequency control, PLC, servo

motor, servo drive and touch screen are supplied by Siemens, Germany,Angle encoder by Nemicon, Japan.Part of the electric components by Schneider, France.
Electric:
Main motor: 2.9 kW,Belt conveyor motor: 0.55 kW
Power: 380 V 50Hz, 3-phase

Specification

Item	Name	Unit	Specification	Remark
1	Capacity	Kg/h	1500~3000
2	Cutting Speed(max)	pcs/min	200
3	Length(max)	m/min	20
4	Thickness of soap(max)	mm	≤70
6	Piece Speed	pcs/min	≤250
7	Lenght	mm	<60
8	Servo Moter	set	2.6KW MPL-A4530-HJ22AA	America Allen-Bradley
9	Gear motor	set	0.25KW	WP/PC13.5
10	Dimension	mm	1350×785×1450
11	Weight	kg	500

Details Images

Recommend Products

Company Profile

Limac Machinery Works Corporation, Lanzhou (LIMAC) is a professional corporation devoted herself to research, development, and manufacturing of all kind of soap machinery and equipment. The corporation owned a creative design and manufacturing team, most of them have thirty years of soap-making machinery design/ manufacturing experience. For years the corporation has produced a number of up-to-date soap-making machinery and equipment. The corporation adopts internationally new mode of cooperation, integrating domestic and foreign advanced technical and production resources, so the machinery and equipment supplied by LIMAC has been highly praised by the soap producers all over the world.

Exhibition

Shipping and Payment

FAQ

1. who are we?
We are based in Gansu, China, start from 2006,sell to Eastern Asia(30.00%),Africa(30.00%),Mid East(20.00%),Northern Europe(10.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
soap making machine,toilet soap production line,laundry soap making machine,packing machine,two colour-sandwich soap production line

4. why should you buy from us not from other suppliers?
Limac Machinery Works Corporation, Lanzhou (LIMAC) is a professional corporation devoted herself to research, development, and manufacturing of all kind of soap machinery and equipment. The corporation owned a creative design and manufacturing team.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,Western Union;
Language Spoken:English,Chinese,Spanish,Portuguese,French,Russian
